The unique double ball and socket design allows you to adjust your mount to the perfect viewing or operating angle, all with the turn of a single knob. This modular design can be configured with a variety of interchangeable components to fit your specific mounting needs.
B Size
Holds 2 lbs / 0.91 KG
1" Ball
Phones, Action Cameras, Light Duty Tablets
C Size
Holds 4 lbs / 1.81 KG
1.5" Ball
Fishfinders, Heavy Duty Tablets
D Size
Holds 6 lbs / 2.72 KG
2.25" Ball
Monitors, Large Fishfinders
E Size
Holds 15 lbs / 6.8 KG
3.38" Ball
Heavy Monitors
Ball Sizes Short Arm Medium Arm Long Arm
B Size Overall Length 2.42" / 6.1468cm 3.73" / 9.47cm 6.00" / 15.24cm
Socket-to-Socket Length 1.75" / 4.45cm 3.00" / 7.62cm 5.31" / 13.49cm
C Size Overall Length 3.56" / 9.04cm 5.69" / 14.45cm 9.13" / 23.19cm
Socket-to-Socket Length 2.50" / 6.35cm 4.66" / 11.84cm 8.00" / 20.32cm
D Size Overall Length 5.10" / 12.95cm 8.44" / 21.44 12.98" / 32.97
Socket-to-Socket Length 3.60" / 9.14cm 6.88" / 17.48cm 11.41" / 28.98cm
E Size Overall Length 7.31" / 18.57cm 12.63" / 32.08cm N/A
Socket-to-Socket Length 4.98" / 12.65cm 9.88" / 25.10cm N/A

RAM® Tough-Tube™ Rod Holder with Round Flush Base

SKU Copied
SKU: RAP-394-SSFMTU
UPC Copied
UPC: 793442941832

RAM® Tough-Tube™ Rod Holder with Round Flush Base
Copy SKU
SKU: RAP-394-SSFMTU
Copy UPC
| UPC: 793442941832

The RAP-394-SSFMTU consists of the Tough-Tube fishing rod holder, 5.08cm (2") long ratchet spline post arm and round flush mounting base. The ratcheting feature allows for the tube to tilt forward and back 180 degrees for optimum viewing angles. The round flush mounting base is designed to accommodate gunwales up to two inches thick, and seat with no visible hardware, this product is ideally suited to a wide variety of applications. Once installed, the post spline can be removed and the hole capped making it water tight. Ideally suited for anything from Kayaks to Tournament boats, this compact and simply design is ready for your next day on the water.

Information

Information

Product Weight
0.56 kg (1.23 lbs)
Product Dimensions
Post Length: 5.08cm (2")
Tube Dimensions
Inside Diameter: 4.83cm (1.9") Inside Length: 25.40cm (10")
Materials
High strength composite
Packaging Type
Poly Bag
Add to Enquiry

Components

RAM Mounts
Copy SKU
RAM-114FMTU
RAM ROD® Round Flush Base
RAM Mounts
Copy SKU
RAP-394-SSTU
RAM® Tough-Tube™ Rod Holder with 2" Ratchet Spline Post Arm


Complete Your Solution

RAM® Post/Spline Extension Arms

RAM Mounts
Copy SKU
RAP-114-EX8
RAM® Adapt-A-Post™ 11" Extension Pole
RAM Mounts
Copy SKU
RAP-114-APB2U
RAM® Adapt-A-Post™ with Adjustable 13.5" Extension Arm
RAM Mounts
Copy SKU
RAP-114-APB3U
RAM® Adapt-A-Post™ with Adjustable 16" Extension Arm
